D100 Steel ball forging heating machine
Features:
| Application | Making grinding ball,steel balls |
| Power | 100 KW-8000 KW |
| Heating method | Induction heating |
Product Detail
Application Video
Product Tags
Product Name: D100 Steel ball forging machine
Typical Application:
D100 Steel ball forging machine designed and manufactured by Forever is used for making steel balls,grinding steel balls, iron ore grinding media. We have series steel ball forging machine such as D20, D40, D60, D60, D80, D100, D120.
In order to make you understand our steel ball forging machine,we give you our D100 steel ball forging machine technical parameters for your reference:
Daily output of D100 Steel ball forging machine
|
Diameter |
Unit weight（kg） |
Production efficiency （pc/minute） |
Hourly Output （MT） |
Daily Output （MT） |
|
Ø100mm |
4.14 |
10 |
2485 |
19.88 |
Specification of D100 Steel ball forging machine
|
Nominal diameter （mm） |
Ball diameter（mm） |
Unit weight （g） |
Number of the balls Per Ton |
Allowable deviation of diameter（mm |
|
70 |
100 |
4140 |
241 |
+1.5 -1.5 |
Induction heating furnace power
| Bars diameter | Ball weight(g) | Production efficiency(T/H) | Furnace power(KW) |
| Ø100mm ball | 4.14 | 2.48 | 942 |
Forever induction heating furnace has widely used for steel ball forging and rolling process, especially we are very familiar with the steel ball production process as we have rich experience and a lot of successful cases. The machines has been exported to Iran, Argentina, Serbia, Mexico and so on.
Manufacturer & supplier of steel ball production line.Welcome to contact us for quotation or other information.
Overseas manager: Tom Wang
Email:tom@foreverfurnace.com
Phone: 0086-13303078975(whatsapp, wechat,line)
Specialist of induction heat treatment furnace in China; Glad to be your business partner in induction heating field.
