Steel bar induction hardening and tempering

Steel bar induction hardening and tempering

Features:

Bar diameter ø20-150mm
Bar length 2-15 meters
 straightness  0.2-0.5mm / m

Product Detail

Application Video

Product Tags

Forever steel bar induction hardening and tempering furnace can be used for various kinds of metal hardening and tempering heat treatment, such as such as 40Cr, 42CrMo, B7, 20CrMnTi, 45 # and other high-carbon steel. The hardening uniformity, strength, hardness and other performance indicators can meet different user needs. Mainly used in screw, drive shaft, high strength bolts and other elongated shaft hardening and tempering heat treatment.

Application for steel bar induction hardening and tempering

Product name Steel bar induction hardening and tempering furnace
Brand Forever
Material 40Cr, 42CrMo, B7, 20CrMnTi, 45 #
Bar diameter ø20-150mm
Bar length 2-15 meters
 straightness  0.2-0.5mm / m
Suitable for  screw, drive shaft, high strength bolts
Process Quenching, tempering, annealing
Quenching temperature 900-950℃
Tempering temperature 600-750℃
Power required 100-5000KW

http://www.hy-inductionheater.com/products/hardening-and-tempering-furnace.html

Why choose Forever steel bar hardening and tempering system?

1. Rich experience: Forever has much cases for bar hardening and tempering process. Knowing different material induction heat treating process requirement, we can help you to choose suitable power, freuqency and configuration.

Steel bar diameter Automatic Control Power Design
Ø10-Ø28 mm IPC Control KGPS350KW Quenching+KGPS160KW Tempering
Ø42-Ø48 mm(Anchor Bolt) PLC Control KGPS250KW Quenching+KGPS160KW Tempering
Ø30-60 mm IPC Control IGBT250KW Quenching+IGBT160KW Tempering
Ø30-Ø60 mm PLC Control KGPS250KW Quenching+KGPS160KW Tempering
Ø35-Ø60 mm IPC Control KGPS250KW Quenching+KGPS160KW Tempering
Ø30-Ø110 mm IPC Control KGPS400KW Quenching+KGPS400KW Tempering
Ø80-v110 mm PLC Control KGPS600KW Quenching+KGPS160KW Tempering

2.Import components: Forever main components are import, so the performance is stable and reliable, which reduce the failure rate greatly. Such as the infrared thermometer is using America Raytek, control system is using Siemens PLC and so on.

3.Automatic loading & unloading device, independent motor for driving. If one drive motor has problem, it will not affect the system running.

4.Simple operation: Forever technician will help users to test and set up the heat treatment process parameters for material hardening and tempering including power, frequency, voltage, water pressure, water flow and so on. The worker only need to choose corresponding recipe, then the system will run as per setting parameters. This reduce the requirement for the operator and make sure the consistency of product quality.
