Pipe induction heating
Application: Pipe Heating & Heating Treating
Material: Carbon steel, Brass,Iron,Alloy steel,Stainless steel,Aluminum
Diameter Allow: Φ20-300mm
Length Allow:Not limited
Pipe induction heating
Years of our experience is in providing manual and automated pipe induction heating furnace for induction heat treating. In addition to experience with many other applications we have developed innovative power supplies able to cover wide frequency ranges and systems for gear tooth hardening, wire and cable heating and pipe welding.
Forever pipe induction heating furnace application
● Pipe annealing
● Pipe hardening / quenching
● Pipe hardening and tempering
Features for pipe induction heating furnace
● Efficient and fast heating
● Accurate, repeatable heating
● Safe heating as there is no flame
● Equipped with infrared thermometer and automatic feeder(optional)
● New type power supply, saving power
NEW TYPE POWER SUPPLY for pipe induction heating furnace
● Power saving 10% -15%:No harmonics, high power factor, load output voltage is high, the load coil current is low,small power consumption.
● Using special transformer for electric furnace.
● The furnace has high reliability: This product uses the latest DSP control technology, with reasonable structure, easy commissioning & reliable performance, which has automatic protection functions including water temperature, water pressure, phase shortage, over-current, under-voltage to ensure The product is running in stable and reliable condition.
● Adopt famous brand components which reduce fault rate and make sure the equipment can run reliably, thereby reducing the shutdown probability caused by failure.
● Advanced technology & Easy maintenance: Having simple structure,perfect protection for control circuit & the most advanced touch screen control, our power supply can show complete failure and find the error.It adopts DSP control technology, which has a high processing speed, which ensures the efficient and orderly operation of the device functions. real-time computing function and real-time simulation and simulation capability.
|Pipe diameter||Automatic control||Power design|
|Ø95，Ø114 mm||PLC Control||KGPS250KW Quenching+KGPS160KW Tempering|
|Ø73.2,Ø88.9,139.7 mm(Drill pipe)||IPC Control||KGPS500KW Quenching+KGPS100KW Tempering|
|Ø30-Ø60 mm||PLC Control||KGPS250KW Quenching+KGPS160KW Tempering|
|Ø35-Ø60 mm||IPC Control||KGPS250KW Quenching+KGPS160KW Tempering|
|Ø30-Ø110 mm||IPC Control||KGPS400KW Quenching+KGPS400KW Tempering|
|Ø80-Ø110 mm||PLC Control||KGPS600KW Quenching+KGPS160KW Tempering|
Welcome you to send us inquiry about pipe induction heating equipment, we will be very glad to provide you with good quality equipment at factory price.
