Induction pipe heater

Induction pipe heater

Features:

Application: Forging , Rolling & Quenching

Material: Carbon steel, Brass,Iron,Alloy steel,Stainless steel,Aluminum

Diameter Allow: Φ20-300mm

Length Allow:Not limited

Product Detail

Application Video

Product Tags

Induction pipe heater

Inductive heating is efficient, easily controlled, uses no energy when not heating, and puts the heat where you want it, when you want it. No idle time, no massive refractories to heat, and close coupling enables you to use energy in the best possible way.

The induction pipe heater can be used in the process of : heating before hot forging & rolling,  hardening,  welding, annealing, tempering, coating. Forever induction pipe heater can be equipped with a wide range to automatic systems. Welcome your inquiry about induction pipe heater.

pipe induction heater

Features for induction pipe heater

 Efficient and fast heating
● Accurate, repeatable heating
● Safe heating as there is no flame
● Equipped with infrared thermometer and automatic feeder(optional)
 New type power supply, saving power

NEW TYPE POWER SUPPLY for induction pipe heater

● Power saving 10% -15%:No harmonics, high power factor, load output voltage is high, the load coil current is low,small power consumption.
● Using special transformer for electric furnace.
 The furnace has high reliability: This product uses the latest DSP control technology, with reasonable structure, easy commissioning & reliable     performance, which has automatic protection functions including water temperature, water pressure, phase shortage, over-current, under-voltage to ensure The product is running in stable and reliable condition.
 Adopt famous brand components which reduce fault rate and make sure the equipment can run reliably, thereby reducing the shutdown probability caused by failure.
 Advanced technology & Easy maintenance: Having simple structure,perfect protection for control circuit & the most advanced touch screen control, our power supply can show complete failure and find the error.It adopts DSP control technology, which has a high processing speed, which ensures the efficient and orderly operation of the device functions. real-time computing function and real-time simulation and simulation capability.

cases

Pipe diameter Automatic control Power design
Ø95,Ø114 mm PLC Control KGPS250KW Quenching+KGPS160KW Tempering
Ø73.2,Ø88.9,139.7 mm(Drill pipe) IPC Control KGPS500KW Quenching+KGPS100KW Tempering
Ø30-Ø60 mm PLC Control KGPS250KW Quenching+KGPS160KW Tempering
Ø35-Ø60 mm IPC Control KGPS250KW Quenching+KGPS160KW Tempering
Ø30-Ø110 mm IPC Control KGPS400KW Quenching+KGPS400KW Tempering
Ø80-Ø110 mm PLC Control KGPS600KW Quenching+KGPS160KW Tempering

As our induction heater is all customized, the above parameters are only for your reference.
