Process flow of hot-rolled deformed steel production line

The deformed bar hot rolling production line : The bending degree of the steel bars should not exceed 4mm per meter, and the total bending degree should not exceed 0.4% of the total length of the steel bars.

After treatment, the overall performance of the same threaded steel should be uniform, and the deviation between the overall yield strength and tensile strength should not exceed 20MPa.

The accessory manufacturer of this hot-rolled threaded steel production line is designated by the steel factory. For example: thyristor Beijing Tsinghua; Reducer motor – Nord, control system hardware, frequency converter – SIEMENS, etc.

Significant advantages of the hot-rolled Deformed bar heat treatment machine :

1. The entire hot rolled threaded steel production line adopts a medium frequency resonant induction heating power supply control, with fully open rectification and fully digital touch screen control program, making production more efficient;

2. The angle between the axis of the roller table and the axis of the workpiece is 18-21 degrees;, The workpiece rotates while advancing at a uniform speed to ensure more uniform heating. The roller table between the furnace bodies is made of 304 non-magnetic stainless steel and water-cooled.

3. The feeding group, inductor group, and discharge group of the hot rolled threaded steel production line are independently controlled, which is conducive to continuous heating without creating gaps between workpieces.

4. Adopting the American Raytheon infrared thermometer and forming a closed-loop control system with the German Siemens S7, accurate temperature control is achieved.

5. Real time display of the status of working parameters at that time, with functions such as workpiece parameter memory, storage, printing, fault display, alarm, etc.

6. Provide remote operation console with touch screen or industrial computer system according to user needs.

7. The steel hot rolling induction heating furnace has a specially customized human-machine interface and highly user-friendly operation instructions.
