PC steel bar induction heating equipment

PC steel bar induction heating equipment

Features:

Application PC steel bar heating, heat treatment
Power 100 KW-10000 KW
Non standard
Professional Customization

Product Detail

Application Video

Product Tags

http://www.hy-inductionheater.com/products/pc-steel-bar-heating-production-line.html

Product NamePC steel bar induction heating equipment

Typical Application:PC steel bar(Steel Bar for Pre-stressed Concrete)processing and manufacturing;

                                  Metal wire hardening, tempering and other heat treatment process.

Heating method: Induction heating

Customized: Yes

http://www.hy-inductionheater.com/products/pc-steel-bar-induction-heating-equipment.html

At present, the PC steel bar induction heat treating equipment produced by Forever Furnace has reached the leading domestic level.

PC steel bar induction heating equipment main technical parameters

Equipment type

AC Input

Power Factor

Rated DC Voltage

Rated DC current

Frequency Range

Heating Process

GZP-600/8

3AC380V
 50/60Hz

Thyristor rectifier 0.92

500V

1200A

6-
   10 kHz

Preheating



IGBT 0.95



GCYP-200/30k

3AC380V
50/60Hz

Thyristor rectifier  0.86

450V

450A

25—
   30 kHz

Heating



IGBT 0.95



GCYP-200/50k

3AC380V
50/60Hz

Thyristor rectifier 0.86

450V

450A

40—
   50 kHz

Hardening



IGBT 0.95



GZP-300/8

3AC380V
50/60Hz

Thyristor rectifier  0.92

500V

600A

6-
   8 kHz

Tempering

PC steel bar induction heating equipment configuration:

1. Induction heating furnace.

2. Input and output roller table

3. Automatic unloading system

4.Medium frequency induction heating inverter

5. Closed cooling water circulation system.

6.Infrared temperature measurement system

The characteristics of PC steel bar induction heating equipment.

1. PC steel bar induction heating equipment is controlled by electromagnetic intermediate frequency induction heating power supply, and the power of medium frequency induction heating equipment can be adjusted.

2.The operating console is equipped with SIEMENS PLC and 10 inch color touch screen to realize data display and query, program control of workpiece and other recording functions, and record data can be used by U disk.

3.Quenching tank: stainless steel tank made of stainless steel sprinkler ring.

4.The power cabinet has protection functions of overpressure, overcurrent and low water pressure.

6. Install the whole copper plate at both ends of the furnace to prevent leakage of magnetic, and chassis is made of aluminum alloy.

Dear buyer,

Please kindly tell us:

The PC steel bar diameter and length?

The power you need or we design for you?

The PC steel bar production capacity?

Then we will help you to choose the suitable induction heating furnace.
